MSI B550M PRO-VDH WIFI Socket AM4/ AMD B550/ DDR4/ SATA3&USB3.2/ M.2/ Micro-ATX Motherboard

Descripción

Mfr Part Number:B550MPVDHWIFI (B550M PRO-VDH WIFI)

CPU:Supports AM4 socket 3rd Gen AMD Ryzen processors, and future AMD Ryzen processors with BIOS update

Chipset:AMD B550 Chipse

Detalles

Memory:

4x DDR4 memory slots, support up to 128GB

– Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC

– Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE

* 1DPC 1R max speed 4400 MHZ

* 1DPC 2R max speed 3733 MHZ

* 2DPC 1R max speed 3866 MHZ

* 2DPC 2R max speed 3466 MHZ

Dual channel memory architecture

Supports non-ECC UDIMM memory

Supports ECC UDIMM memory

Supports un-buffered memory

Expansion Slots:

1x PCIe 4.0/ 3.0 x16 slot (PCI_E1)

2x PCIe 3.0 x1 slots

OnboardGraphics:

1x VGA port, supports resolution of 2048×1536 @50Hz, 2048×1280 @60Hz, 1920×1200 @60Hz

1x DisplayPort, supports a maximum resolution of 4096×2160 @60Hz

1x HDMI port, supports a maximum resolution of 4096×2160 @24Hz

Maximum shared memory of 16 GB

Storage:

AMD B550 Chipset

-4x SATA 6Gb/s ports

-2x M.2 slots (Key M)

-M2_1 slot (from AMD Processor)

*Supports PCIe 4.0/ 3.0 x4

*Supports SATA 6Gb/s

*Supports 2242/ 2260/ 2280storage devices

-M2_2 slot (from AMD B550 chipset)

*Supports PCIe 3.0×4

*Supports 2242/ 2260/ 2280 storage devices

RAID:

Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices

Supports RAID 0 and RAID 1 for M.2 NVMe storage devices

USB:

AMD B550 Chipset

– 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector)

– 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)

AMD Processor

– 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel

Audio:

RealtekALC892 Codec

– 7.1-Channel High Definition Audio

LAN:1x Realtek 8111HN Gigabit LAN controller

Internal Connectors:

1x 24-pin ATX main power connector

1x 8-pin ATX 12V power connector

4x SATA 6Gb/s connectors

2x M.2 slots (M-Key)

1x USB 3.2 Gen 1 5Gbps Type-C port

1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)

2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

1x 4-pin CPU fan connector

1x 4-pin water-pump fan connector

3x 4-pin system fan connectors

1x Front panel audio connector

2x System panel connectors

1x Serial port connector

1x Chassis Intrusion connector

2x 4-pin RGB LED connectors

2x 3-pin RAINBOW LED connectors

1xTPM module connector

1x Clear CMOS jumper

Back PanelPorts:

VGA

USB 3.2 Gen 1 5Gbps Type-A

Keyboard / Mouse

LAN

Flash BIOS Button

DisplayPort

HDMI

USB 2.0

USB 3.2 Gen 1 5Gbps Type-A

Wi-Fi Antenna connectors

3x Audio jacks

Dimensions:

Micro-ATX Form Factor

9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)

Mounting:8mounting holes
